50mm Cast Iron Water Gate Valve Flange Type Fully Guided Flexible Wedge

50mm Cast Iron Water Gate Valve Flange Type Fully Guided Flexible Wedge

    • 50mm Cast Iron Water Gate Valve Flange Type Fully Guided Flexible Wedge
  • 50mm Cast Iron Water Gate Valve Flange Type Fully Guided Flexible Wedge

    Product Details:

    Place of Origin: China
    Brand Name: sufa
    Certification: (DNV)ISO9001,(DNV)ISO14001,CE0035
    Model Number: Z41H-16c

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD 50~500/SET
    Packaging Details: Wooden box, ply-wood box, carton box, pallet
    Delivery Time: within 8-12 working days upon receipt of payment
    Payment Terms: T/T, Western Union, L/C, MoneyGram
    Supply Ability: 500 SETS/MONTH
    Contact Now
    Detailed Product Description
    Name: With Price 50mm Cast Iron Pn16 Dn100 Water Din 3352 F4 Resilient Seated Gate Flanged Valve Size: DN50-600
    Pressure: 1.6-16mpa Temperature: -29-425
    Valve Body Material: WCB Applicable Medium: Water And Oil Vapor, Etc
    High Light:

    solid wedge gate valve

    ,

    stainless steel knife gate valve

    With Price 50mm Cast Iron Pn16 Dn100 Water Din 3352 F4 Resilient Seated Gate Flanged Valve



    Features of Rising-stem Wedge Gate Valves:

    Bolted bonnet
    Outside screw and yoke
    Rising stem and non-rising handwheel
    Flexible wedge, fully guided
    Metal-to-metal seat
    Renewable seat ring and stem backseat
    Manual operation standard, gear operator and actuation available
    Butt weld end
    Flange end: raised face or ring type joint



    Size DN50—DN600
    Nominal Pressure PN10/PN16
    Working Temperature -10°C~120°C
    Suitable Medium Chemicals,air,water,steam,oil, acids,salts,etc



    Standard:
    Design And Manufacture: API 600, API 6D, BS1414,Etc.
    Face To Face (End To End): ANSI B16.10, API 6D,Etc.
    Flanged Connection: ANSI B16.5,Etc.
    Butt Welded End: ANSI B16.25,Etc.
    Test And Inspection: API 598, API 6D,Etc.

    Specification
    Size DN50—DN600
    Nominal Pressure PN10/PN16
    Working Temperature -10°C~120°C
    Suitable Medium Chemicals,air,water,steam,oil, acids,salts,etc
    Standards:
    Design standard DIN3352 F4/F5, MSS SP-70,AWWA C509/515,BS5163
    Face to Face DIN3202 F4/F5, BS5163, ANSI B16.10
    Flange Drilling DIN2533 PN10/PN16, ANSI 125/150,JIS10K
    Test Inspection DIN3230, BS6755
    Materials:
    Body Cast Iron, Ductile Iron
    Wedge Cast Iron, Ductile Iron
    Stem Stainless steel
    Sealing Ring EPDM
    O Ring EPDM




















    50mm Cast Iron Water Gate Valve Flange Type Fully Guided Flexible Wedge 0
