Suzhou Ephood Automation Equipment Co., Ltd.
Gas Regulator,Pressure Transmitter,SUFA Water Valve
 |
| Place of Origin: | Made In China |
| Brand Name: | Tend |
| Model Number: | TZ-8169 |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Tend TZ8169 limit switch,10pcs packed in one carton. |
| Delivery Time: | 5-7 Work-days |
| Payment Terms: | T/T, Western Union, MoneyGram,Payonner |
| Supply Ability: | 1000PCS in 30Days |
| Name: | Tend Brand Limit Switch Model TZ-8169 | Protection Level: | IP65 |
|---|---|---|---|
| Operating Temperature: | -5~+65C | Max. Current: | 5A |
| Max. Voltage: | 250VAC | Operating Speed: | 5mm To 50cm/s |
| Operating Frequency: | 120 Operations/min. | Contact Resistance: | 25mW Max (initial) |
| High Light: | tend brand limit switch,tend pulley limit switch |
||
Tend Limit Switch Spring Type TZ-8169 Position Switch TZ8169
Tend Travel Switch Position Switch Limit Switch TZ-8169
Features
. Built-in basic switch with double spring mechanism
. Long life(10,000,000 mechanical operations)
. Highly rigid construction (Head and cover snugly fit in box)
. Dust-proof and drip-proof construction
. Smooth operation with greater OT
. Easy-to-wire conduit opening design
Note: When you place order, please kindly designate clockwise the movement way and type of contact fitted.
Dimension Drawing:
Model TZ-8168:
