Non Return Stainless Steel Check Valve Spring Loaded Medium Pressure

Product Details:

Place of Origin:	China
Brand Name:	SUFA
Certification:	(DNV)ISO9001,(DNV)ISO14001,CE0035
Model Number:	HQ14X,H42X,H41X,H44X

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	USD 50~500/set
Packaging Details:	Wooden box, ply-wood box, carton box, pallet
Delivery Time:	within 8-12 working days upon receipt of payment
Payment Terms:	T/T, Western Union, MoneyGram, L/C
Supply Ability:	500 sets/month

Contact Now

Detailed Product Description

Size:	DN 40~DN 800	Pressure:	PN10/PN16
Face To Face:	EN558-1	Flange Connection::	EN1092 PN10/16
Temperature:	-30℃- 135℃	Name:	Swing Check Valve (ANSI B16.1)
High Light:	ss swing check valve , stainless steel ball check valve

Swing check valve (ANSI B16.1)

Swing check valve (ANSI B16.1)
Conform to MSS SP-71
Flange Drilled to ANSI B16.1
Face to face dimension conform to ANSI B16.10
Working Pressure: 125 lbs
Suitalbe Media: Water, Oil, Gas

NO.	PART	MATERIAL	STANDARD
1	Bolts	steel	BS970 73A
2	Identification Plate	Aluminium
3	Bonnet	Cast Iron	BS1452 Cr.180
4	Body Gasket	Graphite	BS2494 Type W
5	Stem	Brass	BS2874 CZ12
6	Nuts	Steel	BS970 43A
7	Side Plug	Brass	BS2874 CZ12
8	Gasket	Fiber
9	Hanger Pin	Brass	BS2874 CZ12
10	Hanger	Ductile Iron	BS2789 Gr.420-12
11	Disc	Cast Iron	BS1452 Cr.180
12	Disc Ring	Cast Bronze	BS1400 LG2
13	Washer	steel	BS970 43A
14	Split Pin	Stainless Steel	BS970 420S37
15	Body	Cast Iron	BS1452 Cr.180
16	Stud Bolt	Steel	BS970 43A
