Ductile Iron Fisher Gas Regulator 627 Model Pressure Gas Regulator 250PSI Inlet

Ductile Iron Fisher Gas Regulator 627 Model Pressure Gas Regulator 250PSI Inlet

Ductile Iron Fisher Gas Regulator 627 Model Pressure Gas Regulator 250PSI Inlet
video
Ductile Iron Fisher Gas Regulator 627 Model Pressure Gas Regulator 250PSI Inlet
Product Details:
Place of Origin: Made In China
Brand Name: Fisher
Model Number: 627-1217-29855( 627-496)
Payment & Shipping Terms:
Minimum Order Quantity: 6sets
Price: USD224-260 Each One Set
Packaging Details: 1set packed in one carton ,each carton size is 29*18*18cm,3kg/set.
Delivery Time: 3 work-days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500sets Every Month
Contact Now
Detailed Product Description
Name: Fisher 627 Pressure Gas Regulator Use For LPG End Connetion: 1" NPT
Inlet Pressure: 250psi/17.2Bar;300psi/20.7bar;750psi/51.7bar Outlet Pressure: 5-20psi/15-40psi/35-80psi/70-150psi
Body Material: Ductile Iron Orifice Size: 1/2"
High Light:

fisher regulator valve

,

fisher flow control valve


Ductile Iron Fisher Gas Regulator 627 Model Pressure Gas Regulator 250PSI Inlet 0


Fisher Original 627-496(627-1217-29855) Pressure Gas Regulator



Description

Fisher 627 Series self-operated pressure reducing regulators (Figure 1) are for high and low pressure systems.

Fisher 627 regulators can be used with natural gas, air, or a variety of other gases. Performance characteristics

vary according to construction.



1”NPT of Fisher 627 common used models:

627-1217-29855 , Connection size 1”NPT,Orifice 1/2", Outlet Range 5-20psi, max inlet 250psi.

627-1217-29858 , Connection size 1”NPT, Orifice 1/2", Outlet Range 15-40psi, max inlet 300psi.

627-1217-29860 , Connection size 1”NPT, Orifice 1/2", Outlet Range 35-80psi, max inlet 750psi.

627-1217-29863 , Connection size 1”NPT,Orifice 1/2", Outlet Range 70-150psi, max inlet 750psi.



Table 1. Maximum Inlet Pressures,Outlet Pressure Ranges

TYPE OUTLET PRESSURE RANGE ORIFICE SIZE,
INCHES (mm)
MAXIMUM INLET PRESSURE, PSIG (bar)
627 5 to 20 psig
(0.34 to 1.38 bar)
1/2 (12.7) 250 (17.2)
15 to 40 psig
(1.03 to 2.76 bar)
1/2 (12.7) 300 (20.7)
35 to 80 psig
(2.41 to 5.52 bar)
1/2 (12.7) 750 (51.7)
70 to 150 psig
(4.83 to 10.3 bar)
1/2 (12.7) 750 (51.7)



Fisher Rosemount

Fisher Make 627 Gas Regulator

Emerson Fisher 627 Regulator

Features

Internal Relief Valve

Relief Operation Indicator

Easy to Maintain

Installation Adaptability

Application Versatility

Tamper-Resistant

Wide Range of Flow Capabilities

Specifications

1” NPT End Connection : 627-496,627-497,627-498,627-499

2” NPT End Connection:627-576,627-577,627-578,627-579



Available Constructions

Type 627: Self-operated pressure reducing regulator equipped with a pitot tube for greater regulated capacities (Figure 7).

Type 627R: Type 627 with internal relief and with an open throat (Figure 8).

Type 627M: Type 627 with a stem seal between the body outlet pressure and diaphragm case. Pressure is measured under the diaphragm through the 1/4-inch NPT downstream control line connection (Figure 9).

Type 627MR: Type 627M with internal relief (Figure 10).

Type 627H: Type 627 with a diaphragm limiter to deliver a higher outlet pressure (Figure 11).

Type 627HM: Type 627H with a stem seal between the body outlet pressure and diaphragm case. Pressure is measured under the diaphragm through two 1/4-inch NPT downstream control line connections (Figure 12).

END Connection Sizes

1inch and 2inch

End Connection Styles

1inch or 2-inch body sizes: NPT

1inch or 2-inch (DN 25 or DN50) body sizes: ANSI Class 300 or 600 RF flanged

Maximum Inlet Pressure(1) (Body Rating)

2000 psig (138 bar) for NPT steel, 1480 psig

(102 bar) for RF flanged steel, or 1000 psig (69 bar) for ductile iron

Maximum Valve Disk Inlet Pressure Rating(1)

2000 psig (138 bar) for nylon disk or 1000 psig

(69 bar) for nitrile disk

Pressure Registration
Type 627, 627H or 627R: Internal



Installation

Regulator operation within ratings does not preclude the possibility of damage from debris in the lines or from external sources.

A regulator should be inspected for damage periodically and after any overpressure condition. Like most regulators, 627 Series

regulators have outlet pressure ratings that are lower than their inlet pressure ratings. A pressure-relieving or pressure-limiting

device must be provided by the user for the Types 627, 627H, 627M, and 627HM regulators if the inlet pressure can exceed the

outlet pressure rating, since these regulators do not have internal relief.

Type 627R regulators provide internal relief which limits the total outlet pressure buildup over setpoint. Use Table 3 to determine

the total outlet pressure. This internal relief may be adequate for the application, if not, provide additional pressure relief or a

pressure-limiting device downstream.



WARNING

A regulator may vent some gas to the atmosphere. In hazardous or flammable gas service, vented gas may accumulate

and cause personal injury, death, or property damage due to fire or explosion. Vent a regulator in hazardous gas service

to a remote, safe location away from air intakes or any hazardous area. The vent line or stack opening must be protected

against condensation or clogging.
